👋 Gestura: Gesture-Based Mouse & Voice Control
Gesture-based mouse built using FREE-WILi and Vosk text-to-speech used to increase accessibility in using the web for disabled people, such as amputees and people with lost-mobility in their hands.
💡 Inspiration
At the FREE-WILi workshop held during MHacks this year, our team was inspired by a demo of a Theremin-like device. It used hand gestures—detected via the FREE-WILi’s accelerometer—to control pitch and volume. This sparked an idea: what if we could harness similar gestures for accessibility?
One of our teammates has a family member who suffers from severe Rheumatoid Arthritis, which makes traditional mouse and keyboard usage extremely difficult. We envisioned a system that would allow users to control a computer using just hand gestures and voice commands—no physical touch required.
Moreover, Gestura, which can be attached to the wrist or ankle, has a broader use for amputees and other disabilities to allow people to regain the joy of digital interaction once again.
🧠 What It Does
Gestura enables users to control their mouse using hand gestures and perform mouse actions via voice commands.
- Hand gestures detected by the FREE-WILi move the mouse across the screen.
- Voice commands like:
- “left click”
- “right click”
- “double click”
- “scroll up”
- “scroll down”
- “hold”
- “release”
- “pause input”
- “resume input”
This provides a touch-free, accessible experience for users with limited mobility.
🛠️ How We Built It
We used Python and developed collaboratively with Git and GitHub.
📦 Libraries & Tools Used
FREE-WILi
: Interface with the FREE-WILi accelerometer.pynput
: Control the mouse (movement and clicks).sounddevice
: Capture audio input via microphone.vosk
: Offline voice recognition using vosk-model-small.
🎮 Mouse Movement via Accelerometer
- Captured X and Y acceleration using the FREE-WILi Python library.
- Applied double integration to convert acceleration to position.
- Used pynput.mouse.Controller.position to update the mouse location.
🎙 Voice Control
- Captured real-time audio using the computer’s microphone.
- Processed input through Vosk for speech recognition.
- Mapped voice inputs to actions like:
- click
- right click
- scroll up/down
- pause/resume input, etc.
🚧 Challenges We Ran Into
-
Sensor Drift & Offset: The raw accelerometer data wasn’t zero at rest, causing significant drift after integration.
- Fix: Introduced a deadband (e.g., ) to treat near-zero acceleration as zero.
-
Erratic Movements: Large spikes in acceleration led to uncontrollable motion.
- Fix: Added min/max bounds for both velocity and acceleration to stabilize gestures.
-
Screen Bounds: The mouse pointer would sometimes go off-screen.
- Fix: Implemented position clamping to ensure the mouse stays within the screen (1920x1080).
🏆 Accomplishments We're Proud Of
- Natural-feeling gesture control after some practice.
- User feedback: A friend testing it smiled when the device worked exactly as intended.
- Implemented a broad command set, from clicking to scrolling and pausing/resuming gesture input.
📚 What We Learned
- The FREE-WILi device is powerful and versatile for prototyping assistive tech.
- Sensor data in the real world can be noisy—handling that is both science and art.
- Combining gesture + voice control can dramatically improve accessibility.
🚀 What’s Next for Gestura
- 🛠️ Build a gesture calibration tool to personalize the experience.
- 🧠 Add machine learning to adapt gesture detection to each user over time.
- 🌐 Integrate with web browsers for scroll, tab switch, and navigation.
- 🎤 Use the FREE-WILi’s microphone for full-device integration (once streaming support is added).
🧩 Built With
freewili
git
github
pynput
python
sounddevice
vosx
